INSTRUŌ íre 外部訊號輸入模組 External Signal Input

Name: INSTRUŌ íre 外部訊號輸入模組 External Signal Input
Brand: INSTRUŌ
Price: 13200 TWD
Availability: OutOfStock

Free shipping orders over NTD 3,000

NT$ 13,200

Earn 132 points with this purchase

Installment Info: (Details )

3 months 0 interest, per month NT$ 4,400

6 months 0 interest, per month NT$ 2,200

Type

Qty

Status: 預購商品 (約 10~15 個工作天)

Payment:

Free 1-year Warranty (except all cable, accessories and modulars) (Details)

Warranty Exclusions: Cables, power adapters and other accessories included in the box, Teenage Engineering Pocket Operator series, Modular synthesizers, Behringer HA400/MX400, MIDI Solutions series, microphone stands, hard cases, pedals and other accessories

This product has been viewed 3 times

NT$ 13,200

íre - Mic / Line External Input Interface with CV Extraction 外部訊號輸入模組

蘇格蘭模組品牌 Instruō 歷時數年研發的外部輸入前置放大模組，透過 XLR / 6.3mm 複合插孔，將麥克風、樂器或線路訊號直接引入 Eurorack 系統。採用變壓器輸入電路（Mic 端）與 6070 風格 FET 前置放大電路（Line / Instrument 端），內建 Envelope Follower 與 Comparator，讓外部音訊即時化為動態 CV 控制來源。

產品特色

雙路徑前置放大電路

・麥克風端採變壓器輸入設計，音質純淨、阻抗匹配精準

・樂器／線路端採 6070 風格 FET 前置放大，呈現溫暖管味音色特性

・組合式 XLR / 6.3mm Combo Jack，單一端口即可接麥克風或樂器

靈活的輸入增益控制

・48V Phantom Power 供電容式麥克風使用

・-20 dB Pad 可處理音量過大的訊號來源

・High-Pass Filter 消除低頻隆隆聲與麥克風操作噪音

音訊轉 CV 萃取

・內建 Envelope Follower，具備 AR（Attack / Release）控制，隨音訊動態輸出 CV

・內建 Comparator，將音訊動態轉換為 Gate 訊號，與 Eurorack 系統深度整合

詳細規格

連接

・音訊輸入：XLR / 6.3mm Combo Jack（Mic 或 Instrument / Line）

・音訊輸出：3.5mm Eurorack

・CV 輸出：Envelope Follower

・Gate 輸出：Comparator

輸入功能

・Phantom Power：48V

・Pad：-20 dB

・High-Pass Filter：內建

電源

・+12V：35 mA

・-12V：35 mA

・+5V：0 mA

尺寸

・寬度：8 HP

・深度：27 mm
